How Security Gateways Impact DMARC, SPF & DKIM | EasyDMARC

Understanding the Relationship Between Security Gateways and DMARC

16 Min Read

Email authentication protocols like SPF, DKIM, and DMARC play a critical role in protecting domains from spoofing and phishing. However, when SEGs are introduced into the email path, the interaction with these protocols becomes more complex.

Security gateways(SEGs) are a core part of many organizations’ email infrastructure. They act as intermediaries between the public internet and internal mail systems, inspecting, filtering, and routing messages.

This blog examines how security gateways handle SPF, DKIM, and DMARC, with real-world examples from popular gateways such as Proofpoint, Mimecast, and Avanan. We’ll also cover best practices for maintaining authentication integrity and avoiding misconfigurations that can compromise email authentication or lead to false DMARC failures.

Security gateways often sit at the boundary between your organization and the internet, managing both inbound and outbound email traffic. Their role affects how email authentication protocols behave.

  • An inbound SEG examines emails coming into your organization. It checks SPF, DKIM, and DMARC to determine if the message is authentic and safe before passing it to your internal mail servers.
  • An outbound SEG handles emails sent from your domain. It may modify headers, rewrite envelope addresses, or even apply DKIM signing. All of these can impact SPF,  DKIM, or DMARC validation on the recipient’s side.

Understanding how SEGs influence these flows is crucial to maintaining proper authentication and avoiding unexpected DMARC failures.

Inbound Handling of SPF, DKIM, and DMARC by Common Security Gateways

When an email comes into your organization, your security gateway is the first to inspect it. It checks whether the message is real, trustworthy, and properly authenticated. Let’s look at how different SEGs handle these checks.

Avanan (by Check Point)

  • SPF: Avanan verifies whether the sending server is authorized to send emails for the domain by checking the SPF record.
  • DKIM: It verifies if the message was signed by the sending domain and if that signature is valid.
  • DMARC: It uses the results of the SPF and DKIM check to evaluate DMARC. However, final enforcement usually depends on how DMARC is handled by Microsoft 365 or Gmail, as Avanan integrates directly with them.

Avanan offers two methods of integration:

1. API integration: Avanan connects via APIs, no change in MX, usually Monitor or Detect modes.
2. Inline integration: Avanan is placed inline in the mail flow (MX records changed), actively blocking or remediating threats.

Proofpoint Email Protection

  • SPF: Proofpoint checks SPF to confirm the sender’s IP is authorized to send on behalf of the domain. You can set custom rules (e.g. treat “softfail” as “fail”).
  • DKIM: It verifies DKIM signatures and shows clear pass/fail results in logs.
  • DMARC: It fully evaluates DMARC by combining SPF and DKIM results with alignment checks. Administrators can configure how to handle messages that fail DMARC, such as rejecting, quarantining, or delivering them. Additionally, Proofpoint allows whitelisting specific senders you trust, even if their emails fail authentication checks.

Integration Methods

  1. Inline Mode: In this traditional deployment, Proofpoint is positioned directly in the email flow by modifying MX records. Emails are routed through Proofpoint’s infrastructure, allowing it to inspect and filter messages before they reach the recipient’s inbox. This mode provides pre-delivery protection and is commonly used in on-premises or hybrid environments.
  2. API-Based (Integrated Cloud Email Security – ICES) Mode: Proofpoint offers API-based integration, particularly with cloud email platforms like Microsoft 365 and Google Workspace. In this mode, Proofpoint connects to the email platform via APIs, enabling it to monitor and remediate threats post-delivery without altering the email flow. This approach allows for rapid deployment and seamless integration with existing cloud email services.

Mimecast

  • SPF: Mimecast performs SPF checks to verify whether the sending server is authorized by the domain’s SPF record. Administrators can configure actions for SPF failures, including block, quarantine, permit, or tag with a warning. This gives flexibility in balancing security with business needs.
  • DKIM: It validates DKIM signatures by checking that the message was correctly signed by the sending domain and that the content hasn’t been tampered with. If the signature fails, Mimecast can take actions based on your configured policies.
  • DMARC: It fully evaluates DMARC by combining the results of SPF and DKIM with domain alignment checks. You can choose to honor the sending domain’s DMARC policy (none, quarantine, reject) or apply custom rules, for example, quarantining or tagging messages that fail DMARC regardless of the published policy. This allows more granular control for businesses that want to override external domain policies based on specific contexts.

Integration Methods

  1. Inline Deployment: Mimecast is typically deployed as a cloud-based secure email gateway. Organizations update their domain’s MX records to point to Mimecast, so all inbound (and optionally outbound) emails pass through it first. This allows Mimecast to inspect, filter, and process emails before delivery, providing robust protection.
  2. API Integrations: Mimecast also offers API-based services through its Mimecast API platform, primarily for management, archival, continuity, and threat intelligence purposes. However, API-only email protection is not Mimecast’s core model. Instead, the APIs are used to enhance the inline deployment, not replace it.

Barracuda Email Security Gateway

SPF: Barracuda checks the sender’s IP against the domain’s published SPF record. If the check fails, you can configure the system to block, quarantine, tag, or allow the message, depending on your policy preferences.

DKIM: It validates whether the incoming message includes a valid DKIM signature. The outcome is logged and used to inform further policy decisions or DMARC evaluations.

DMARC: It combines SPF and DKIM results, checks for domain alignment, and applies the DMARC policy defined by the sender. Administrators can also choose to override the DMARC policy, allowing messages to pass or be treated differently based on organizational needs (e.g., trusted senders or internal exceptions).

Integration Methods

  1. Inline mode (more common and straightforward): Barracuda Email Security Gateway is commonly deployed inline by updating your domain’s MX records to point to Barracuda’s cloud or on-premises gateway. This ensures that all inbound emails pass through Barracuda first for filtering and SPF, DKIM, and DMARC validation before being delivered to your mail servers.
  2. Deployment Behind the Corporate Firewall: Alternatively, Barracuda can be deployed in transparent or bridge mode without modifying MX records. In this setup, the gateway is placed inline at the network level, such as behind a firewall, and intercepts mail traffic transparently. This method is typically used in complex on-premises environments where changing DNS records is not feasible.

Cisco Secure Email (formerly IronPort)

Cisco Secure Email acts as an inline gateway for inbound email, usually requiring your domain’s MX records to point to the Cisco Email Security Appliance or cloud service.

SPF: Cisco Secure Email verifies whether the sending server is authorized in the sender domain’s SPF record. Administrators can set detailed policies on how to handle SPF failures.

DKIM: It validates the DKIM signature on incoming emails and logs whether the signature is valid or has failed.

DMARC: It evaluates DMARC by combining SPF and DKIM results along with domain alignment checks. Admins can configure specific actions, such as quarantine, reject, or tag, based on different failure scenarios or trusted sender exceptions.

Integration methods

  1. On-premises Email Security Appliance (ESA): You deploy Cisco’s hardware or virtual appliance inline, updating MX records to route mail through it for filtering.
  2. Cisco Cloud Email Security: Cisco offers a cloud-based email security service where MX records are pointed to Cisco’s cloud infrastructure, which filters and processes inbound mail.

Cisco Secure Email also offers advanced, rule-based filtering capabilities and integrates with Cisco’s broader threat protection ecosystem, enabling comprehensive inbound email security.

Outbound Handling of SPF, DKIM, and DMARC by Common Security Gateways

When your organization sends emails, security gateways can play an active role in processing and authenticating those messages. Depending on the configuration, a gateway might rewrite headers, re-sign messages, or route them through different IPs – all actions that can help or hurt the authentication process. Let’s look at how major SEGs handle outbound email flow.

Avanan – Outbound Handling and Integration Methods

Outbound Logic

Avanan analyzes outbound emails primarily to detect data loss, malware, and policy violations. In API-based integration, emails are sent directly by the original mail server (e.g., Microsoft 365 or Google Workspace), so SPF and DKIM signatures remain intact. Avanan does not alter the message or reroute traffic, which helps maintain full DMARC alignment and domain reputation.

Integration Methods

1. API Integration: Connects to Microsoft 365 or Google Workspace via API. No MX changes are needed. Emails are scanned after they are sent, with no modification to SPF, DKIM, or the delivery path.

  • How it works: Microsoft Graph API or Google Workspace APIs are used to monitor and intervene in outbound emails.
  • Protection level: Despite no MX changes, it can offer inline-like protection, meaning it can block, quarantine, or encrypt emails before they are delivered externally.
  • SPF/DKIM/DMARC impact: Preserves original headers and signatures since mail is sent directly from Microsoft/Google servers.

2. Inline Integration: Requires changing MX records to route email through Avanan. In this mode, Avanan can intercept and inspect outbound emails before delivery. Depending on the configuration, this may affect SPF or DKIM if not properly handled.

  • How it works: Requires adding Avanan’s MX record. All outbound mail is routed through Avanan’s security gateway.
  • Protection level: Traditional inline security with full visibility and control, including encryption, DLP, policy enforcement, and advanced threat protection.
  • SPF/DKIM/DMARC impact: SPF configuration is needed by adding Avanan’s include mechanism to the sending domain’s SPF record. The DKIM record of the original sending source is preserved.

For configurations, you can refer to the steps in this blog.

Proofpoint – Outbound Handling and Integration Methods

Outbound Logic

Proofpoint analyzes outbound emails to detect and prevent data loss (DLP), to identify advanced threats (malware, phishing, BEC) originating from compromised internal accounts, and to ensure compliance. Their API integration provides crucial visibility and powerful remediation capabilities, while their traditional gateway (MX record) deployment delivers true inline, pre-delivery blocking for outbound traffic.

Integration methods

1. API Integration: No MX record changes are required for this deployment method. Integration is done with Microsoft 365 or Google Workspace.

  • How it works: Through its API integration, Proofpoint gains deep visibility into outbound emails and provides layered security and response features, including:
    • Detect and alert: Identifies sensitive content (Data Loss Prevention violations), malicious attachments, or suspicious links in outbound emails.
    • Post-delivery remediation (TRAP): A key capability of the API model is Threat Response Auto-Pull (TRAP), which enables Proofpoint to automatically recall, quarantine, or delete emails after delivery. This is particularly useful for internally sent messages or those forwarded to other users.
    • Enhanced visibility: Aggregates message metadata and logs into Proofpoint’s threat intelligence platform, giving security teams a centralized view of outbound risks and user behavior.
  • Protection level: API-based integration provides strong post-delivery detection and response, as well as visibility into DLP incidents and suspicious behavior.
  • SPF/DKIM/DMARC impact: Proofpoint does not alter SPF, DKIM, or DMARC because emails are sent directly through Microsoft or Google servers. Since Proofpoint’s servers are not involved in the actual sending process, the original authentication headers remain intact.

2. Gateway Integration (MX Record/Smart Host): This method requires updating MX records or routing outbound mail through Proofpoint via a smart host.

  • How it works: Proofpoint acts as an inline gateway, inspecting emails before delivery. Inbound mail is filtered via MX changes; outbound mail is relayed through Proofpoint’s servers.
  • Threat and DLP filtering: Scans outbound messages for sensitive content, malware, and policy violations.
  • Real-time enforcement: Blocks, encrypts, or quarantines emails before they’re delivered.
  • Policy controls: Applies rules based on content, recipient, or behavior.
  • Protection level: Provides strong, real-time protection for outbound traffic with pre-delivery enforcement, DLP, and encryption.
  • SPF/DKIM/DMARC impact: Proofpoint becomes the sending server:
    • SPF: You need to configure ProofPoint’s SPF.
    • DKIM: Can sign messages; requires DKIM setup.
    • DMARC: DMARC passes if SPF and DKIM are set up properly.

Please refer to this article to configure SPF and DKIM for ProofPoint.

Mimecast – Outbound Handling and Integration Methods

Outbound Logic

Mimecast inspects outbound emails to prevent data loss (DLP), detect internal threats such as malware and impersonation, and ensure regulatory compliance. It primarily functions as a Secure Email Gateway (SEG), meaning it sits directly in the outbound email flow. While Mimecast offers APIs, its core outbound protection is built around this inline gateway model.

Integration Methods

1. Gateway Integration (MX Record change required)

This is Mimecast’s primary method for outbound email protection. Organizations route their outbound traffic through Mimecast by configuring their email server (e.g., Microsoft 365, Google Workspace, etc.) to use Mimecast as a smart host. This enables Mimecast to inspect and enforce policies on all outgoing emails in real time.

  • How it works:
    You configure your outbound flow by either:
    • Updating outbound routing in your email system (smart host settings), or
    • Using Mimecast SMTP relay to direct messages through their infrastructure.
      Mimecast then scans, filters, and applies policies before the email reaches the final recipient.
  • Protection level:
    Full real-time, inline protection, including:
    • Advanced DLP: Identifies and prevents sensitive data leaks.
    • Impersonation and Threat Protection: Blocks malware, phishing, and abuse from compromised internal accounts.
    • Email Encryption and Secure Messaging: Applies encryption policies or routes messages via secure portals.
  • Regulatory Compliance: Enforces outbound compliance rules based on content, recipient, or metadata.
  • SPF/DKIM/DMARC impact:
    • SPF: Your SPF record must include Mimecast’s SPF mechanism based on your region to avoid SPF failures.
    • DKIM: A new DKIM record should be configured to make sure your emails are DKIM signed when routing through Mimecast.
    • DMARC: With correct SPF and DKIM setup, Mimecast ensures DMARC alignment, maintaining your domain’s sending reputation. Please refer to the steps in this detailed article to set up SPF and DKIM for Mimecast.

2. API Integration (Complementary to Gateway)

Mimecast’s APIs complement the main gateway by providing automation, reporting, and management tools rather than handling live outbound mail flow. They allow you to manage policies, export logs, search archived emails, and sync users.

APIs enhance visibility and operational tasks but do not provide real-time filtering or blocking of outbound messages. Since APIs don’t process live mail, they have no direct effect on SPF, DKIM, or DMARC; those depend on your gateway (smart host) setup.

Barracuda – Outbound Handling and Integration Methods

Outbound Logic

Barracuda analyzes outbound emails to prevent data loss (DLP), block malware, stop phishing/impersonation attempts from compromised internal accounts, and ensure compliance. Barracuda offers flexible deployment options, including both traditional gateway (MX record) and API-based integrations. While both contribute to outbound security, their roles are distinct.

Integration Methods

1. Gateway Integration (MX Record / Smart Host) — Primary Inline Security
This is Barracuda’s traditional method for comprehensive outbound email security. Organizations route all outbound email through Barracuda’s cloud-based Email Security Gateway by either pointing their domain’s MX records to Barracuda or configuring their internal mail server (e.g., Microsoft 365, Exchange) to use Barracuda as a smart host.

  • How it works: All outbound emails pass through Barracuda’s security stack for real-time inspection, threat blocking, and policy enforcement before delivery.
  • Protection level:
    Full inline, real-time protection including:
    • Comprehensive DLP (blocking, encrypting, or quarantining sensitive content)
    • Outbound spam and virus filtering
    • Enforcement of compliance and content policies

This approach offers a high level of control and immediate threat mitigation on outbound mail flow.

  • SPF/DKIM/DMARC impact:
    • SPF: Update SPF records to include Barracuda’s sending IPs or SPF include mechanism.
    • DKIM: Currently, no explicit setup is needed; DKIM of the main sending source is preserved.

Refer to this article for more comprehensive guidance on Barracuda SEG configuration.

2. API Integration (Complementary & Advanced Threat Focus)
Barracuda also offers API integration, primarily through Barracuda Sentinel and the Barracuda Email Protection suite for Microsoft 365. This method complements gateway protection by focusing on advanced threats, such as Business Email Compromise (BEC), account takeover, and sophisticated phishing that may evade traditional gateways.

  • How it works: The API accesses cloud email environments to analyze historical and real-time data, learning normal communication patterns to detect anomalies in outbound emails. It also supports post-delivery remediation, enabling the removal of malicious emails from internal mailboxes after sending.
  • Protection level: Advanced AI-driven detection and near real-time blocking of outbound threats, plus strong post-delivery cleanup capabilities.
  • SPF/DKIM/DMARC impact: Since mail is sent directly by the original mail server (e.g., Microsoft 365), SPF and DKIM signatures remain intact, preserving DMARC alignment and domain reputation.

Cisco Secure Email (formerly IronPort) – Outbound Handling and Integration Methods

Outbound Logic

Cisco Secure Email protects outbound email by preventing data loss (DLP), blocking spam and malware from internal accounts, stopping business email compromise (BEC) and impersonation attacks, and ensuring compliance. Cisco provides both traditional gateway appliances/cloud gateways and modern API-based solutions for layered outbound security.

Integration Methods

1. Gateway Integration (MX Record / Smart Host) – Cisco Secure Email Gateway (ESA)
This is Cisco’s established and powerful method for comprehensive outbound email security. It uses physical or virtual appliances or cloud gateways positioned inline in the mail flow.

  • How it works: Organizations update MX records to route mail through the Cisco Secure Email Gateway or configure their mail server (e.g., Microsoft 365, Exchange) to smart host outbound email via the gateway. All outbound mail is inspected and policies enforced before delivery.
  • Protection level:
    Full real-time, inline protection including:
    • Granular DLP (blocking, encrypting, quarantining sensitive content)
    • Outbound spam and malware filtering to protect IP reputation
    • Email encryption for sensitive outbound messages
    • Comprehensive content and attachment policy enforcement

2. API Integration – Cisco Secure Email Threat Defense
Cisco’s cloud-native API solution primarily targets Microsoft 365 environments, focusing on deep visibility and detection of advanced outbound threats.

  • How it works: Integrates directly via API with Microsoft 365 (and potentially Google Workspace), continuously monitoring email metadata, content, and user behavior across inbound, outbound, and internal messages. Leverages Cisco’s threat intelligence and AI to detect anomalous outbound activity linked to BEC, account takeover, and phishing.
  • Post-Delivery Remediation: Automates the removal or quarantine of malicious or policy-violating emails from mailboxes even after sending.
  • Protection level: Advanced, AI-driven detection of sophisticated outbound threats with real-time monitoring and automated remediation. Complements gateway filtering by adding cloud-native visibility and swift post-send action.
  • SPF/DKIM/DMARC impact: Since emails are sent directly by the original mail server, SPF and DKIM signatures remain intact, preserving DMARC alignment and domain reputation.

If you have any questions or need assistance, feel free to reach out to EasyDMARC technical support.

Various authors from EasyDMARC teams have contributed to our blog during company's lifetime. This author brings everyone together.
